car washing machine, Product
YBJ-919
原价为：¥26,800.00。¥24,700.00当前价格为：¥24,700.00。
| Configuration | YBJ-919 | YBJ-919F |
| Equipment dimensions
(L x W x H) mm |
(9000-11000)x3800x3000 mm | 11000x3800x3000 mm |
| Washable vehicle dimensions (mm) | 6000x2000x2000 mm | 6000x2000x2000 mm |
| Mounting dimensions (mm) | (11000-15000)x4000x3100 mm | 12000x4000x3100 mm |
| Power supply | Three-phase four-wire:380V/50Hz（60Hz) | Three-phase four-wire:380V/50Hz（60Hz) |
| Air supply pressure | Approx. 6–8 kPa | Approx. 6–8 kPa |
| Water consumption | Approx. 200 kg/unit | Approx. 200 kg/unit |
| Car washing capability | Approx. 40 units/hour | Approx. 40 units/hour |
| Top brush | Group 1 | Group 1 |
| Side brush | Four groups | Four groups |
| Skirt brush | Four groups | Four groups |
| Stationary air-drying system | Configuration not available（/） | Standard equipment（φ） |
| High-pressure oscillating water jet | Standard equipment（φ） | Standard equipment（φ） |
| Bottom-spray system | Optional（○） | Optional（○） |
| Foam system | Optional item ( △ ) with metering pump liquid supply | Optional item ( △ ) with metering pump liquid supply |
| High-gloss wax system | Optional（○） | Standard equipment（φ） |
| Unattended system | Optional（○ (Can interface with gas station systems.) | Optional（○ (Can interface with gas station systems.) |
| ○ Optional φ Standard equipment /Configuration not available △Optional configuration for liquid supply via metering pump | ||
Description of Car Wash Machine Specifications and Features
| project | Configuration | illustrate |
| CPU module | DVP40ES200R | Delta Controller |
| Human-Machine Interface (Touchscreen) | MCGS | MCGS Operating System |
| Frame structure | Double C-shaped box-type structure | Rust protection via pickling, phosphating, and hot-dip galvanizing, followed by a powder-coated surface finish. |
| High-pressure water system | 3 sets of spray nozzle | Effectively washes away mud, sand, and loose dust from the vehicle’s surface. |
| Pull-type transverse brush | Variable-frequency controlled brake motor | Precisely controlled balancing structure; automatic detection of scrubbing pressure. |
| Large upright brush | Parallel-type large vertical brush | Precise control of the left and right vertical brush angles. Covers the rear section and tail of the vehicle; safe washing with no blind spots. |
| Skirt brush | Tilted structure | Dense bristles for a more thorough wash of the vehicle’s side skirts. |
| Data system | Touchscreen display | Detailed statistics on the number of cars washed that day and the total number of cars washed. |
| Fault self-diagnosis system | Touchscreen display | Full Chinese-language self-diagnosis and alarm notifications, along with fault analysis and troubleshooting guidance. |
